Minitiger WIFI Smart Touch Switch APP Wireless Remote Light Wall Switch Crystal Glass Panel Works With Alexa / Google Home
| Input Voltage
|| AC 90-250V 50/60HZ
| Output Voltage
|| AC 90-250V 50/60HZ
| maximum Power
| Standby Power
| Transmission Distance
| Working Temperature
| Control Mode
|| Touch control, mobile phone remote control, voice control
| Wi-Fi Protocol
|| IEEE 802.11 b/g/n
| Connection mode
|| Zero line, fire line
| APP language categories
Chinese, Traditional Chinese, English, Arabic, Spanish, French,
Russian, German, Italian, Japanese, and Holland
| APP language change mode
|| Automatically switch according to the user’s phone language, default English
|| Mobile phone remote control
| Connection mode
|| WiFi 2.4G app connection (PS: Doesn’t support 5G)
|| PC material, 4mm thickness tempered glass
|| 1 year
|| FCC,CE, ROHS
eWeLink XSmart Home
Our Application is eWeLink which can compatible with more than 100+ kinds of Smart Home Products.
It will be the most suitable APP for your smart home.You can control almost all smart appliances via only one APP.
Google Home + Amazon Alexa
Our All of our WIFI Smart Home Products (Including WIFI Remote Switches & Plug with Sockets) can work with Google Home & Amazon Alexa efficiently.
I do believe that our WIFI Products are the best choice for everyone.
1. Power up the wall switch.
2. Press the button for a few seconds until it fast blinks to enter into WIFI pairing status.
3. The blinking way is: blink 3 times and on repeatedly.
For Android users, please select the first icon and click NEXT.
For IOS users, please select the corresponding icon, click NEXT.EWeLink will auto-search and connect to the device.
4. Input your home SSID & password:
If no password, keep it blank.
Now eWeLink only support2 4G WIFI
communication protocol, 5G-WiFi is not supported.
5. Name the device to complete.
6. Maybe the device is “Offline” on eWeLink, for the device
needs 1-2 minutes to connect to your router and server.
When the green LED on, the device is “Online”. if eWeLink shows still Offline”, please close eWeLink and re-open.
1.Install the switch with electricity off
2.Do not exceed the maximum load
3.Do not test without the glass panel.Please install the glass panel before switch on the power.
Problems and solutions
Read the detailed FAQ on ltead Smart Home Forum. If below
answers can’t solve your problem, please submit a feedback
1. My device has added successfully but stays “Offline?The newly added device need 1-2 min to connect to your
router and the Internet. If it stays offline for a long time,please judge the problem by the green led status:
Green led quickly blinks one time and repeats, which meansdevice failed to connect to the router. The reason may be
you have entered wrong WiFi password or your device is too faraway from the router, which causes a weak WiFi signal. The
device can not be added to the 5G-wifi-router, only the 2.4G-wifi is OK. At last, make sure that your router is MAC-open.
Green led slowly blinks one time and repeats, which meansthe device has connected to router and server but failed to
beadded to the device list. Then power on the device again, if itstill not working. just add the device again.
Green led quickly blinks twice and repeats, this means the
device has connected to the router but failed to connect to theserver. Then please confirm your WiFi router works normally.
2. Why the APP can’t find the device in pairing status?Answers: That’s because of your phone’s cache. Please
close the WLAN of your phone then open it after a minute. Atthe same time, please power off the device if you can, thenpower up to try again,
3. My WiFi is expired, can I connect the devices to LAN?Answers: It doesn’t support to be controlled by LAN You’llneed to connect it to a WiFi with Internet.
1. WiFi remote control and synchronous device statusTurn on/off by tapping device icon on App.
Device statusalways simultaneously dispiay on APP.
2. Share Control
The owner can share the devices to other eWeLink accounts.While sharing devices,
both should stay online on eWeLink(keep the screen lighten). Because if the account you want toshare
is not online, he/she will not receive the invitationmessage.
How to make it possible? Firstly click Share, input the
eWeLink account (phone number or email address) you wantto share, tick the timer permissions
(edit/delete/change/enable) you want to give. then clickNext. The other account will
receive an invitation message.Click Accopt, the device has shared successfully.
The otheruser will have access to control the device.
3. Timing schedules
Support max 8 enabled single/repeat/countdown timing schedules each device.
4. Scene/Smart Scene
Scene allows triggering on/off your devices automatically.Scene Settings is in the upper right corner of Device List.
You can set up scenes or smart scenes to trigger on/off the device.Users should select Click to execute” in the condition,
adddifferent existing devices, name the scene and save it.
5, Set default device status
In Device Setting. you can set default device status to ON orOFF when the device is powered on.
One device one owner. Other people can not add the devicesthat have already been added.
If you want to add your deviceto another account, don’t forget to delete it first.
It will auto-remind you of new firmware or version. Please update as soon as you can.
